Tyre Selector
tyre michelin xsm d2 pro image large full persp perspective
MICHELIN XSM D2+ PRO
/1
  • Robustness
  • Underground Mining

MICHELIN XSM D2+ PRO

Extreme conditions demand tough tyres

  • Increased load capacity
  • Improved aggression resistance
  • Improved tyre life
Loading… dimensions for this product
Technical information
Close
MICHELIN
XSM D2+ PRO
Select a dimension
back
Select a dimension
  • 17.5R25 L5*** TL
  • 18.00R25 L5*** TL
  • 26.5R25 L5S*** TL
  • 29.5R29 L5S*** TL
Close
MICHELIN
XSM D2+ PRO
Select a dimension
back
Select a dimension
  • 17.5R25 L5*** TL
  • 18.00R25 L5*** TL
  • 26.5R25 L5S*** TL
  • 29.5R29 L5S*** TL

Increased Load Capacity

Up to 18% more load capacity. (1)

Improved Aggression Resistance (2)

Due to new cables and NRF technology (reinforced sidewall plies).

Improved Tyre Life

Tyre life improved (3) in the harshest of conditions thanks to optimised tread compounds (3).

Picto pro line header Tyre

NRF technology

Two extra plies added to the tyre structure contain cross-woven nylon cords built into the rubber for greater resistance and robustness.

MICHELIN® Pro Line of Underground Tires – NRF Technology

RELATED SERVICES AND SOLUTIONS

MICHELIN MEMS solutions : TPMS for rigid dumper trucks

Monitor tyre temperature and pressure of your mine and quarry vehicles with ease.

Thanks to the innovative MICHELIN Temperature and Pressure Monitoring System (TPMS) offer, ensures you get the best performance from your tyre, improve safety of your employees and increase your productivity.

FIND YOURS
MICHELIN Consulting and Services : increase your productivity of your mining site

Request tailored recommendations to increase your site productivity

Need to reduce your operational cost, increase tyre life, or load of your vehicle while ensuring safety of your staff, ... Our expert team are here to identify the best improvement areas for YOUR site.

DISCOVER MICHELIN CONSULTING&SERVICES
  • Technical Specifications
  • Pressures (bar and psi) & Loads (kg and lbs)

Technical Specifications

Product MICHELIN XSM D2+ PRO - 17.5R25
Overall Diameter 1396 mm / 55 inch
Section width 453 mm / 18 inch
Recommended rims 14.00/1.5
Rolling circumference (mm) 4246
Filling volume 100% (lts) 272 l / 72 gal
Tread depth 78 mm / 3.1 inch
Loaded radius 641 mm
TRA code L-5
CAI 822869

Pressures (bar and psi) & Loads (kg and lbs)

Take the load and type of work to be done into account when adjusting the pressure**

bar

psi

3

44

3.5

51

4

58

4.5

65

5

73

5.5

80

6

87

6.5

94

7

102
(kg - lbs) loader-group-2

front-laden

4750

10472

5450

12015

6000

13228

6500

14330

7100

15653

7500

16535

8000

17637

8500

18739

10000

22046

rear-unladen

3800

8378

4360

9612

4800

10582

5200

11464

5680

12522

6000

13228

6400

14110

6800

14991

8000

17637

**IMPORTANT

The inflation pressure must always be appropriate for the load per tyre, the speed of travel and the work to be done. Our recommendations above are provided subject to changes made after the date of publication of these tables (December 2020). Technical data is subject to change without prior notice.

Picto visuel contact hero image yellow bib heart Tyre

Find out more…

Find all the technical and commercial information in our product data sheet:

Download (625.76Kb)
LEGAL NOTICES

(1) Based on comparisons of the MICHELIN® XSM® D2+ PRO and X MINE® D2 PRO to the MICHELIN® XSM® D2+ and MICHELIN® X MINE® D2, as set forth in the 2018 Michelin Data Book. Actual results may vary.
(2) Based on computer modeling comparisons of the MICHELIN® XSM® D2 + PRO and X MINE® D2 PRO tyres compared to MICHELIN® XSM® D2+ and MICHELIN X MINE® D2 tyres. Actual results may vary.
(3) Based upon improved aggression resistance and on computer modeling comparing the tread compounds included in the MICHELIN® XSM® D2+ PRO to the MICHELIN® XSM® D2+. Actual results may vary.
